74 Unidrive M SI-PROFIBUS User Guide
Issue Number: 3
5
1
Quick Stop Not
Activated
Quick Stop command is not active.
0
Quick Stop
Activated
Quick Stop command is active.
6
1
Switch-on
Inhibited
Power supply switched on, the drive is inhibited.
0
Switch-on Not
Inhibited
Power supply switched on,
7
1 Warning Present Not Implemented
0
No Warning
Present
Not Implemented
8
1
Speed Error
Within Tolerance
‘At Speed’ (Pr 10.006) = 1
0
Speed Error Out
Of Tolerance
‘At Speed’ (Pr 10.006) = 0
9
1
Control
Requested
The automation system is requested to accept
control.
0
No Control
Requested
Control only possible on the device itself.
10
1
Speed Or
Frequency
Reached/
Exceeded
‘At Speed’ (Pr 10.006) = 1 or
‘Above Set Speed’ (Pr 10.007) = 1
0
Speed Or
Frequency Not
Reached
‘At Speed’ (Pr 10.006) = 0 and
‘Above Set Speed’ (Pr 10.007) = 0
11-15 0 Reserved
Bit Value Function Comments
