5.2 Single line descriptions
5.2.1 Menu 0 - Set-up
Table 5.1 Menu 0 single line descriptions
Menu 0 within the option module, is also displayed in the drive menu 15, 16 or 17
depending on which slot the option module is installed to. However, the functionality of
all parameters remains the same.
Menu 0 is not available in firmware version 01.01.01.02 and previous versions.
5.2.2 Menu 1 - PROFIBUS set-up
Parameter Range(Ú)Default(Ö)Type
S.00.001 Module ID 0 to 65535 443 RO Num ND NC PT
S.00.002
Firmware
Version
00.00.00.00 to 99.99.99.99 RO Num ND NC PT
S.00.003
Hardware
Version
00.00 to 99.99
RO Num ND NC PT
S.00.004
Serial
Number LS
0 to 99999999 RO Num ND NC PT
S.00.005
Serial
Number MS
0 to 99999999 RO Num ND NC PT
S.00.006
Module
status
Initializing (0), Ok (1), Config (2),
Error (3)
RO Num ND NC PT
S.00.007 Module reset Off (0) or On (1) Off (0) RW Bit NC
S.00.008
Module
default
Off (0) or On (1) Off (0) RW Bit NC
NOTE
Parameter Range(Ú) Default(Ö) Type
S.01.001
Enable
Profibus
Interface
Off (0) or On (1) On (1) RO Bit
S.01.002
Reset Profibus
Interface
Off (0) or On (1) Off (0) RW Bit
S.01.003
Default
Profibus
Interface
Off (0) or On (1) Off (0) RW Bit
S.01.004
Profibus node
address
0 to 126 126 RW Num US
S.01.005 Baud rate
Auto-detect (0), 12 Mbps (1),
6 Mbps (2), 3 Mbps (3), 1.5 Mbps (4),
500 kbps (5), 187.5 kbps (6),
93.75 kbps (7), 45.45 kbps (8),
19.2 kbps (9), 9.6 kbps (10)
RO Txt ND NC PT
S.01.006
Profibus
Network
Diagnostic
Network OK (0), Initialization (1),
Initialized(2), No network data (3),
First failure (4), Second failure (5),
Third Failure (6)
RO Txt ND NC PT
S.01.007
Cyclic data
transfers per
second
0 to 9999 messages/s
RO Num ND NC PT
