Table 14.10 CT Single Word Bit Positions
Table 14.11 CT Single Word Bit Definitions
14.6 Reading parameters using CT Single Word
To read 32-bit parameters using the non-cyclic channel, the following “telegrams” must
be transmitted to construct the final message:
• Telegram 1 - define menu number
• Telegram 2 - define parameter number
• Telegram 3 - request high data byte
• Telegram 4 - request mid-high data byte
• Telegram 5 - request mid-low data byte
• Telegram 6 - request low data byte
b15 b14 b13 b12 b11 b10 b9 b8
READ ERR Reserved 32-BIT Stamp Number
b7 b6 b5 b4 b3 b2 b1 b0
Data Byte
Bit Function Values Description
0 to 7 Data 0 to 255
Depending on the stamp number of the telegram, this
byte contains the menu, parameter or data byte.
8 to 11
Stamp
number
0 to 6
Indicates the stamp number of the word. This shows
which part of the message is currently in progress.
Setting the stamp number to 0 resets the internal
non-cyclic state machine.
12 32-BIT
0 = 16-bit
data
1 = 32-bit
data
Specifies whether a 16-bit or 32-bit data value is to be
written to or read from the drive. If 32-BIT is set,
telegrams 5 and 6 will be used to transfer the
additional data bytes.
13 Reserved 0 Reserved for future use. Always set to 0.
14 ERR
0 = Data
OK
1 = Error
Indicates the success or failure of the message.
Failure could occur if the parameter does not exist, or
is a read-only or write-only parameter. This bit will
also be set if the parameter value is out of range in
16-bit mode.
15 READ
0 = Write
1 = Read
Defines whether the data word is part of a READ or
WRITE cycle.
Setting the stamp number to 0 resets the internal non-cyclic state machine. Allowing a
new message to be started.
CT Single Word non-cyclic data uses only one word of data, when using this with data
alignment set to 32 requires two 16-bit words. In this mode only the least significant word
of the 32-bit word is used.
NOTE
NOTE
