6.3 Module menu 1 - PROFIBUS Set-up
Menu 1 contains all the parameters relating to the set-up of the PROFIBUS interface on
the SI-PROFIBUS module.
This parameter displays a value of On (1) to indicate that the PROFIBUS Interface has
been enabled.
Changes to the SI-PROFIBUS configuration will not take effect until the SI-PROFIBUS
has been reset.
To reset the SI-PROFIBUS:
•Set Pr S.01.002 to On (1).
• When the sequence has been completed, Pr S.01.002 will be reset to OFF (0).
• The SI-PROFIBUS will reset using the updated configuration.
This sequence does NOT store the SI-PROFIBUS configuration parameters in the drive
or the SI-PROFIBUS flash memory. This parameter will change back to OFF
immediately, and as such the change may not be visible in the display.
The SI-PROFIBUS option module can be set to it's factory default configuration.
This can be performed as follows:
•Set Pr S.01.003 to On
• Reset the PROFIBUS interface by setting Pr S.01.002 to On (1).
• SI-PROFIBUS communications will be stopped
• The host drive will load and store its default parameter values
• Default parameter values for the SI-PROFIBUS will be loaded
• The SI-PROFIBUS will reset using the default values
If the host drive is defaulted (see the relevant Drive User Guide for details), it will also
clear the current configuration for the slot SI-PROFIBUS is installed to.
Enable PROFIBUS interface
S.01.001
Default On (1)
Range OFF (0) or On (1)
Access RO
Reset PROFIBUS interface
S.01.002
Default OFF (0)
Range OFF (0) or On (1)
Access RW
Default PROFIBUS Interface
S.01.003
Default OFF (0)
Range OFF (0) or On (1)
Access RW
NOTE
NOTE
