14.2 PPO Types
SI-PROFIBUS supports all five types of Parameter Process data Object (PPO) defined
by the PROFIdrive profile V4. The PROFIdrive profile features four specific functions
which the SI-PROFIBUS translates into appropriate drive functions:
• PROFIdrive control word
• Main Setpoint
• PROFIdrive status word
• Main Actual Value
Each PPO mode uses a unique combination of features which are detailed in the
following sections.
14.2.1 PPO 1
Table 14.3 PPO 1 mapping structure
14.2.2 PPO 2
Table 14.4 PPO 2 mapping structure
Do not confuse PPO 4 mode with Mode 2 - PPO 4 word non-cyclic data, they are not the
same.
NOTE
IN Data Function OUT
Data
Function
word 0
Mode 2 non cyclic data
(PPO 4-word)
word 0
Mode 2 non cyclic data
(PPO 4-word)
word 1 word 1
word 2 word 2
word 3 word 3
word 4 PROFIdrive status word word 4 PROFIdrive control word
word 5 Main Actual Value word 5 Main Setpoint
IN Data Function OUT
Data
Function
word 0
Mode 2 non cyclic data
(PPO 4-word)
word 0
Mode 2 non cyclic data
(PPO 4-word)
word 1 word 1
word 2 word 2
word 3 word 3
word 4 PROFIdrive status word word 4 PROFIdrive control word
word 5 Main Actual Value word 5 Main Setpoint
word 6
User configurable mapping
using
Pr S.02.004 to Pr S.02.007
word 6
User configurable mapping using
Pr S.03.004 to Pr S.03.007
word 7 word 7
word 8 word 8
word 9 word 9
