6 Parameters
6.1 Menus
Table 6.1 SI-PROFIBUS internal menus
S is the slot number where the module is installed.
The module's menu 0 is also displayed in menu 15, 16 or 17 depending on which slot
the module is installed to. Table 6.2 below shows the location of the module's menu 0 on
the drive.
Menu 0 is not available in firmware version 01.01.01.02 and previous versions.
For M200, M300 and M400 drives, the module menu 0 will be displayed in drive menu
15.
Table 6.2 SI-PROFIBUS menu 0 locations on M700/M800.
L
6.2 Module menu 0 - module information
The firmware version of the option module is in the format of ww.xx.yy.zz.
Menu Description
S.0 Module information
S.1 PROFIBUS set-up
S.2 Input mapping
S.3 Output mapping
S.4 Fault values
S.9 Resources
Slot number Menu 0 locations
115
216
317
NOTE
NOTE
Module ID Code
S.00.001
Default 443
Range 0 to 999
Access RO
SI-PROFIBUS firmware version
S.00.002
Default N/A
Range 00.00.00.00 to 99.99.99.99
Access RO
