EMKO TRANS-AMF - Additional LCD Data Pages; Engine Status Parameters

Generator Page5:
Q1: Generator reactive power L1
Q2: Generator reactive power L2
Q3: Generator reactive power L3
Generator Page6:
S1: Generator apparent power L1
S2: Generator apparent power L2
S3: Generator apparent power L3
Generator Page7:
S
S
S
P: Generator total active power
Q: Generator total reactive power
S: Generator total apparent power
Generator Page8:
kWh: Generator active energy
KVArh: Generator reactive energy
Engine Page1:
Oil pressure: Oil pressure sender input value
Temperature: Coolant temperature sender input value
Speed: Engine speed
Engine Page2:
Conf. AI1: Configurable Analog Input-1 value
Conf. AI2: Configurable Analog Input-2 value
Battery volt: Battery supply voltage
10
GENERATOR
Q1: 40kVAr
Q2: 40kVAr
Q3: 40kVAr
On load
GENERATOR
S1: 210kVA
S2: 210kVA
S3: 210kVA
On load
GENERATOR
P: 510kW
Q: 120kVAr
S: 630kVA
On load
S
S
S
GENERATOR
kWh : 30600
kVArh: 7200
On load
ENGINE
Oil Pressure: 4.3bar
Temperature : 30ºC
Speed : 1500rpm
On load
ENGINE
Conf.AI1 : 96%
Conf.AI2 : 40ºC
Battery volt: 12.0Vdc
On load
