EMKO TRANS-AMF - Page 9

Mains Page1:
V12: Mains voltage L1-L2
V23: Mains voltage L2-L3
V31: Mains voltage L3-L1
V1: Mains voltage L1-N
V2: Mains voltage L2-N
V3: Mains voltage L3-N
Mains Page2:
Fq: Mains frequency
Phase Seq.: Mains phase sequence
Generator Page1:
V12: Generator voltage L1-L2
V23: Generator voltage L2-L3
V31: Generator voltage L3-L1
V1: Generator voltage L1-N
V2: Generator voltage L2-N
V3: Generator voltage L3-N
Generator Page2:
I1: Load Current L1
I2: Load Current L2
I3: Load Current L3
PF1: Generator power factor L1
PF2: Generator power factor L2
PF3: Generator power factor L3
Generator Page3:
Fq: Generator frequency
Ie: Earth Current
Phase Seq.: Generator phase sequence
Generator Page4:
P1: Generator active power L1
P2: Generator active power L2
P3: Generator active power L3
9
Data display pages on the LCD display;
MAINS
V12: 380V V1: 220V
V23: 380V V2: 220V
V31: 380V V3: 220V
Wait for start
MAINS
Fq:50.0Hz
Phase seq.: L1 L2 L3
Wait for start
GENERATOR
V12: 380V V1: 220V
V23: 380V V2: 220V
V31: 380V V3: 220V
On load
GENERATOR
I1: 26A PF1: -0.84
I2: 23A PF2: -0.80
I3: 25A PF3: -0.82
On load
GENERATOR
Fq:50.0Hz Ie: 0A
Phase seq.: L1 L2 L3
On load
GENERATOR
P1: 170kW
P2: 170kW
P3: 170kW
On load
