Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
158 Endress+Hauser
Resetting totalizer 1 automatically
By means the Analog Alarm Block
With the aid of the Analog Alarm and Discrete Output Block, totalizer 1 in the DP_Flow
Transducer Block can be reset automatically.
The DP_FLOW Transducer Block is connected to an Analog Input Block by means of the
Channel/CHANNEL parameter (Channel/CHANNEL = 6). In the Analog Alarm Block the
High High Limit/HI_HI_LIM parameter is used to set a limit value at which the totalizer
should be reset to zero. As soon as this limit value is overshot, the Analog Alarm Block
transmits an alarm value to the downstream Discrete Output Block. The latter changes its
output from 0 to 1 and thus resets the totalizer in the DP_FLOW Transducer Block to 0. The
output of the Analog Alarm Block changes back to 0.
By means the Analog Input Block
With the aid of Analog Input and Discrete Output Block, totalizer 1 in the DP_Flow
Transducer Block can be reset automatically.
The DP_FLOW Transducer Block is connected to an Analog Input Block by means of the
Channel/CHANNEL parameter (Channel/CHANNEL = 6). In the Analog Input Block the
High High Limit/HI_HI_LIM parameter is used to set a limit value at which the totalizer
should be reset to zero. As soon as this limit value is overshot, the Analog Input Block
transmits an alarm value to the downstream Discrete Output Block. The latter changes its
output from 0 to 1 and thus resets the totalizer in the DP_FLOW Transducer Block to 0. The
output of the Analog Input Block changes back to 0.
TOTALIZER_1_FLOAT/
TOTALIZER_1
OUT
IN
HI_HI_LIM
HI_HI_ALM
OUT_ALM
CAS_IN_D
OUT_D
↓↓↓↓↓
→
DP Flow
Transducer Block →
Analog Input Block 3
CHANNEL = 6
L_TYPE = Direct
→
Analog Alarm
Block →
Discrete Output
Block
CHANNEL = 21
→
TOTALIZER_1_VALUE/
TOTALIZER_1
HIHI_ALM_OUT_D
IN
OUT_D
↓↓↓
→
DP Flow
Transducer Block →
Analog Input Block 3
CHANNEL = 6
L_TYPE = Direct
→
Discrete Output
Block
CHANNEL = 21
→
