Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
200 Endress+Hauser
Reset Totalizer 1/
TOTALIZER_1_RESET
Options
Index: 27
Data type: unsigned8
Access: OOS
You reset totalizer 1 to zero with this parameter.
Options:
• Abort (do not reset)
• Reset
Factory setting:
Abort
Totalizer 1/
TOTALIZER_1_STRING_VALU
E
Display
Index: 28
Data type: visible string
Access: read only
Displays the total flow value of totalizer 1. You can reset the value with the
Reset Totalizer 1/TOTALIZER_1_RESET parameter. The Totalizer 1 overflow/
TOTALIZER_1_STRING_OVERFLOW parameter displays the overflow.
Example: The value 123456789 m
3
is indicated as follows:
– Totalizer 1: 3456789 m
3
– Totalizer 1 overflow: 12 E7 m
3
Totalizer 1 overflow/
TOTALIZER_1_STRING_OVER
FLOW
Display
Index: 29
Data type: visible string
Access: read only
Displays the overflow value of totalizer 1.
See also Totalizer 1/TOTALIZER_1_STRING_VALUE.
Totalizer 2/TOTALIZER_2
Display
Index: 30
Data type: float
Access: read only
The Totalizer 2/TOTALIZER_2 parameter is a structured parameter consisting
of two elements.
VALUE
• Displays the total flow value of totalizer 2.
STATUS
• Displays the status.
You can transmit the value and status of this parameter via the Channel/
CHANNEL parameter ( ä 211) in the Analog Input Block. The Channel/
CHANNEL must be set to "7" for this purpose.
Eng. unit total. 2/
TOTALIZER_2_UNIT
Options
Index: 31
Data type: unsigned16
Access: OOS
Select the unit for totalizer 2.
Prerequisite:
• Deltabar M differential pressure transmitter
Factory setting:
m³
Totalizer 2 mode/
TOTALIZER_2_MODE
Entry
Index: 32
Data type: unsigned8
Access: OOS
Define the behavior of the totalizer.
Options:
• Balanced: Integration of all measured flows (positive and negative).
• Pos. flow only: only positive flows are integrated.
• Neg. flow only: only negative flows are integrated.
• Hold: The totalizer is stopped and keeps its current value.
Total. 2 failsafe/
TOTALIZER_2_FAIL_SAFE_M
ODE
Options
Index: 33
Data type: unsigned8
Access: OOS
Select the mode for totalizer 2 in the event of an error.
Currently, only the "Actual" mode can be selected, i.e. totalizer 2 continues to
count in the event of an error.
DP_FLOW Transducer Block
Parameter Description
