Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
208 Endress+Hauser
9.12.4 Analog Input Block (function block)
Alarm behav. P/
UNDER_OVER_PRESSURE_BE
HAVIOR
Options
Index: 30
Data type: unsigned8
Access: OOS
This parameter specifies how the unit should react if the sensor limit is
exceeded or undershot.
Options:
•Warning
•Alarm
Factory setting
Warning
Analog Input Block
Parameter Description
Static Revision/ST_REV
Display
Index: 1
Data type: usigned16
Access: read only
Displays the counter for static parameters of the Analog Input Block.
The counter is incremented by one with each change of a static parameter of the
Analog Input Block. The counter counts up to 65535 and then starts again at zero.
Tag Description/
TAG_DESC
Entry
Index: 2
Data type: octet string
Access: wr for Auto,
OOS
Enter a description for the related block or the measuring point e.g. TAG number
(max. 32 alphanumeric characters).
Strategy/STRATEGY
Entry
Index: 3
Data type: unsigned16
Access: auto, man, OOS
Enter user-specific value for grouping and thus faster evaluation of the blocks.
Grouping takes place by entering the same numerical value for the Strategy/
STRATEGY parameter of the block in question.
Input range:
0...65535
Factory setting:
0
Alert Key/ALERT_KEY
Entry
Index: 4
Data type: unsigned8
Access: auto, man, OOS
Enter the identification number for the measuring device or for each individual block.
The control level uses this identification number to sort alarm and event messages and
initiate other processing steps.
Input range:
1...255
Factory setting:
0
Block Mode/
MODE_BLK
Selection, display
Index: 5
Data type: DS-69
Access: auto, man, OOS
The Block Mode/MODE_BLK parameter is a structured parameter consisting of four
elements. The Analog Input Block supports the "Auto" (automatic), "Man" (value and
status of the OUT parameter can be specified directly by the operator) and OOS (out of
service) modes.
TARGET
• Change the block mode.
ACTUAL
• Displays the current block mode.
PERMITTED
• Displays the modes supported by the block.
NORMAL
• Displays the block mode during standard operation.
Diagnostic Transducer Block
Parameter Description
