Endress+Hauser Cerabar M - Page 218

Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
218 Endress+Hauser
Select Alarm Mode/
ALARM_MODE
Index: 43
Data type: DS66
Access: wr for Auto,
OOS, Man
Facilitates alarm mode settings for the Alarm Output Discrete/ALM_OUT_D
parameter.
Options
•Low Cutoff/LOW_CUT
• HiHi or LoLo Alarm activates ALARM_OUT_D/HIHI_LOLO
• Hi or Lo Alarm activates ALARM_OUT_D/HI_LO
Alarm Output Discrete/
ALM_OUT_D
Index: 44
Data type: DS-66
Access: wr for Auto,
OOS, Man
The Alarm Output Discrete/ALM_OUT_D parameter comprises the 4 alarms (LO,
LOLO, HI, HIHI). The 3 values make it possible to view the current, activated alarm
depending on the alarm selected.
Options:
• LOW_CUT alarm (default): The ALM_OUT_D output returns 1 if the LOW_CUT
function restricts the measured value to 0. Otherwise the ALM_OUT_D output is 0.
• HIHI/LOLO collective alarm: The ALM_OUT_D output returns 1 if the measured
value corresponds to the HIHI limit value or overshoots this value if the measured
value corresponds to the LOLO limit value or undershoots this value. The output
returns 0 if the measured value is between the limit values HIHI and LOLO.
• HI/LO collective alarm: The ALM_OUT_D output returns 1 if the measured value
corresponds to the HI limit value or overshoots this value if the measured value
corresponds to the LO limit value or undershoots this value. The output returns 0 if
the measured value is between the limit values HI and LO.
Block Error Description/
BLOCK_ERR_DESC_1
Index: 45
Data type: unsigned32
Access: wr for Auto,
OOS, Man
Detailed description of the errors that occur within the block.
Error messages:
•RS_BLOCK in OOS
• Block not scheduled
• Channel undefined
•L-Type undefined
• AI / TRD unit inconsistent
Analog Input Block
Parameter Description
