Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 217
Fsafe type/
FSAFE_TYPE
Options
Index: 37
Data type: unsigned8
Access: man, OOS
If the Analog Input Block receives an input value or simulation value with the status
BAD, the Analog Input Block continues working with the failsafe mode defined by
means of this parameter.
The following options are available by means of the Fsafe type/FSAFE_TYPE
parameter:
• Last Good Value
The last valid value is used for further processing with the status UNCERTAIN.
• Fail Safe Value
The value specified by means of the Fsafe value/FSAFE_VALUE parameter is used
for further processing with the status UNCERTAIN. See this table, Fsafe type/
FSAFE_TYPE parameter description.
•Wrong Value
The current value is used for further processing with the status BAD.
The failsafe mode is also activated if the "Out of service" option was selected by means
of the Block Mode/MODE_BLK parameter, "Target" element.
Factory setting:
Fail Safe Value
Fsafe value/
FSAFE_VALUE
Entry
Index: 38
Data type: float
Access: wr for Auto,
OOS, Man
Enter the value for the "Fail Safe Value" option selected via the Fsafe type/
FSAFE_TYPE parameter.
See also this table, Fsafe type/FSAFE_TYPE parameter description.
Factory setting:
0
High High Alarm
Output Discrete/
HIHI_ALM_OUT_D
Index: 39
Data type: DS66
Access: wr for Auto,
OOS, Man
Digital outputs (1 or 0) for limit value monitoring. If the Process Value/PV High High
Limit/HI_HI_LIM, the output is set to "1".
High alarm output
discrete/
HI_ALM_OUT_D
Index: 40
Data type: DS66
Access: wr for Auto,
OOS, Man
Digital outputs (1 or 0) for limit value monitoring. If the Process Value/PV High
Limit/HI_LIM, the output is set to "1".
Low alarm output
discrete/
LO_ALM_OUT_D
Index: 41
Data type: DS66
Access: wr for Auto,
OOS, Man
Digital outputs (1 or 0) for limit value monitoring. If the Process Value/PV Low Low
Limit/LO_LO_LIM, the output is set to "1".
Low Low Alarm Output
Discrete/LOLO_ALM_
OUT_D
Index: 42
Data type: DS66
Access: wr for Auto,
OOS, Man
Digital outputs (1 or 0) for limit value monitoring. If the Process Value/PV Low
Limit/LO_LIM, the output is set to "1".
Analog Input Block
Parameter Description
