Endress+Hauser Cerabar M - Page 216

Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
216 Endress+Hauser
Low Low Priority/
LO_LO_PRI
Entry
Index: 31
Data type: unsigned8
Access: auto, man, OOS
Specify how the system should react if the Low Low Limit/LO_LO_LIM limit value
( ä 216) is undershot.
Input range:
• 0...15
• 0: The alarm is suppressed.
• 1: The alarm is detected by the system. No notification is issued.
• 2: Reserved for block alarms.
• 3-7: Informative alarm with increasing priority,
3: Low priority, 7: High priority
• 8-15: Critical alarm with increasing priority,
8: Low priority, 15: High priority
Factory setting:
0
Low Low Limit/
LO_LO_LIM
Entry
Index: 32
Data type: float
Access: auto, man, OOS
Enter lower critical limit value.
Input range:
Range and units of Output Scale/OUT_SCALE ( ä 216)
Factory setting:
–INF
Low Low Alarm/
LO_LO_ALM
Display, selection
Index: 33
Data type: DS-71
Access: auto, man, OOS
Status display for the Low Low Limit/LO_LO_LIM limit value ( ä 216).
High High Alarm/
HI_HI_ALM
Display, selection
Index: 33
Data type: DS-71
Access: auto, man, OOS
Status display for the High High Limit/HI_HI_LIM limit value ( ä 215).
High Alarm/HI_ALM
Display, selection
Index: 34
Data type: DS-71
Access: auto, man, OOS
Status display for the High Limit/HI_LIM limit value ( ä 215).
Low Alarm/LO_ALM
Display, selection
Index: 35
Data type: DS-71
Access: auto, man, OOS
Status display for the Low Limit/LO_LIM limit value ( ä 215).
Analog Input Block
Parameter Description
