Parameter description (Local operation and FieldCare) Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus
152 Endress+Hauser
OUTPUT UNIT (023)
Selection
Select the unit for the measured value display and the MEASURED VALUE parameter
(→ ä 201).
!
Note!
The selected unit is used only to describe the measured value. This means that when
selecting a new output unit, the measured value is not converted.
Example:
• Current measured value: 0.3 ft
• New output unit: m
• New measured value: 0.3 m (9.8 ft)
Options:
•%
• mm, cm, dm, m
•ft, inch
•cm
3
, dm
3
, m
3
,m
3
E
3
•l, hl
•ft
3
, ft
3
E
3
• gal, bbl, Igal
•g, kg, t
• lb, ton, oz
Factory setting:
%
HEIGHT UNIT (003)
Selection
Select the height unit. The measured pressure is converted to the chosen height unit
using the DENSITY UNIT and ADJUST DENSITY parameters.
Options:
•mm
•cm
•dm
•m
•inch
•ft
Factory setting:
m
CALIBRATION MODE (008)
Selection
Select the calibration mode.
Options:
•Wet
Wet calibration takes place by filling and emptying the container. The measured
pressure is converted to the chosen height unit using the HEIGHT UNIT, DENSITY
UNIT and ADJUST DENSITY parameters. In the case of two different levels, the level,
volume, mass or percentage value entered is assigned to the converted height value.
•Dry
Dry calibration is a theoretical calibration. For this calibration, you specify two height-
level value pairs via the EMPTY CALIB., EMPTY HEIGHT, FULL CALIB. and FULL
HEIGHT parameters.
Factory setting:
Dry
DENSITY UNIT (001)
Selection
Select the density unit. The measured pressure is converted to a height using the HEIGHT
UNIT, DENSITY UNIT and ADJUST DENSITY parameters.
Options:
•g/cm
3
•kg/dm
3
•kg/m
3
• US lb/in
3
• US lb/ft
3
Factory setting:
kg/dm
3
ADJUST DENSITY (007)
Entry
Enter the density of the fluid. The measured pressure is converted to a height using the
HEIGHT UNIT, DENSITY UNIT and ADJUST DENSITY parameters.
Factory setting:
1.0
Table 9: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL SELECTION "Level easy height"
Parameter name Description
