Parameter description (Local operation and FieldCare) Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus
172 Endress+Hauser
CUSTOMER UNIT V (608)
Entry
Enter text (unit) for customer-specific volume unit.
You can enter a maximum of eight alphanumeric characters here. → See also CUST.
UNIT. FACT. V.
Prerequisite:
• COMB. MEASURAND = Height and volume, HEIGHT UNIT = User unit
• COMB. MEASURAND = %-height and volume,
HEIGHT UNIT = User unit
!
Note!
Only the first five characters are shown on the local operation. For example, if the
customer-specific unit "crates" was selected, only "crate" would be displayed.
If the unit contains a slash, up to eight characters can be shown on the local operation.
The maximum number of characters in the counter is again limited to five. For example if
the customer-specific unit "crates/m2" was selected, "crate/m2" would be displayed.
FieldCare accepts units with eight characters at most. The slash counts as one character.
Factory setting:
_ _ _ _ _ _ _ _
CUST. UNIT FACT. V (607)
Entry
Enter the conversion factor for a customer-specific volume unit.
The conversion factor must be entered in relation to the SI unit "m
3
". → See also
CUSTOMER UNIT V.
Prerequisite:
• COMB. MEASURAND = Height and volume, HEIGHT UNIT = User unit
• COMB. MEASURAND = %-height and volume,
HEIGHT UNIT = User unit
Example:
– You want the measured value to be displayed in "buckets".
– MEASURED VALUE = 0.01 m3 i 1 bucket
– Entry CUSTOMER UNIT V: bucket
– Entry CUST. UNIT FACT. V: 100
– Result: MEASURED VALUE = 1 bucket
Factory setting:
1.0
MASS UNIT (709)
Selection
Select the mass unit for the 2nd measured value.
Prerequisite:
• COMB. MEASURAND = Height and mass or %-height and mass
Options:
•g
•kg
•t
•oz
•lb
•ton
•User unit, → see also the following parameter descriptions for CUSTOMER UNIT M
and CUST. UNIT. FACT. M
!
Note!
Following a change in the unit, the digital output value of the Analog Input value OUT
and the local operation or the MEASURED VALUE no longer display the same value.
→ See also parameter descriptions for XD SCALE, OUT SCALE and OUT value.
Factory setting:
kg
Table 13: OPERATING MENU → SETTINGS → BASIC SETUP "Level", LEVEL MODE "Height linearized"
Parameter name Description
