EMC note:
Adherence to the limits that are specified in EMC product standard DIN EN 61800-03: 2001-02,
has been confirmed in the test laboratory:
Interference emission
1)
: first environment / restricted availability
Interference immunity: second environment
The following installation recommendations are made in accordance with the situation in the test
laboratory.
1)
Conducted emissions must be attenuated by using suitable filtering in the power supply.
ENGEL supply cord set cables in standard lengths of 2m and 5m for optimal operation of the device. Other
cable lengths can be supplied on demand.
Requirements for the motor cable:
Minimum cross-sectional area for DSV13x: 2,5mm² (Attend voltage drop on the cable!)
The motor cable must have an overall shielding which has to be connected to protective earth on the DSV side.
Flexibility and temperature range have to be according to the specific application.
The Protective Earth (PE) is connected to X1.4 and the shielding to the shield connector of X2
Signal wires within the motor cable (parking brake) have to be shielded separately and need separate connection
from the motor wires by a shielding which, for safety reasons, is connected to protective earth.
Recommendation: Ölflex- Servo 700CY 4x 2,5mm² + (2 x 2 x 0,75mm²) StD-CY
Supplier: Lapp GmbH, Stuttgart, Germany; www.lappkabel.de
Requirements for the resolver- , incremental- u. tacho cable:
Use twisted pair cables. Corresponding cable pairs are used for corresponding signals (resolver signal, incremental
encoder, tacho voltage + und -)
The cable must have an overall-shielding. The shield must be connected to protective earth on the DSV side.
Recommendation: Ölflex- Servo 720 CY 4x (2x 0,25mm²) + 2x 1mm² CY
Supplier: Lapp GmbH, Stuttgart, Germany; www.lappkabel.de
