Digital Servo Controllers
DSV 130 / DSV 132 / DSV 133
Operating Manual Rev. 1.8 www.engelantriebe.de Page 37
11.3.3 Menu ‘Monitor’
The monitor window can be configured by switching on or off the display for different values.
Notice:
The refresh rate of single values decreases with rising number of monitor windows.
Close the unnecessary windows.
Speed: actual and set speed
Current: actual and set current
Position: actual and set position
Contouring error: Deviation of the position in position control mode
I²t- Monitoring: Shows the drive’s overload capacity. Increasing display means “drive overloaded”. At 100%
integrator value, the output current is reduced to rated current. Overloading is re-enabled below
50% integrator value.
Motor temperature: Only with linear temperature probe
Power-stage temperature: Temperature of the power electronics heat-sink
Digital I/O: Shows the state of all digital in- and outputs
11.3.4 Menu ‘Set value – RS232’
On clicking the menu item “Set value RS232” a sliding bar is displayed. When the RS232 is selected as source of set
values, this bar represents the demanded value for current, respectively speed. Moving the bar left / right increases /
decreases the set value accordingly.
11.3.5 Menu ‘Options’
COM-Port: Select COM port in use
Language: Select language: English / German / French
11.3.6 Menu ‘Info’
Displays information about DSerV
