Digital Servo Controllers
DSV 130 / DSV 132 / DSV 133
Operating Manual Rev. 1.8 www.engelantriebe.de Page 36
11.3.1 Menu ‘File’
This menu allows access to the following functions:
Connect: Establishes a communication link with the DSV via RS232
Disconnect: Stops communication with the DSV and frees the serial interface.
Parameter Up-/Download:
Upload: Uploads the current set of DSV parameters and saves it to a *.par file. The file can be amended with a
description and saved to disk.
Download: Downloads a set of parameters from a *.par file to the DSV. For an overview all available files are
listed together with their description.
Firmware download: Opens the dialog to download Firmware into the DSV. Follow the instructions. Necessary *.hex files
are provided on request.
Close: Closes DSerV.
11.3.2 Menu ‘Optimisation’
This menu allows for manual adjustment of all DSV parameters.
Notice:
Parameter settings transmitted via the TRANSMIT – button are available in the servo-
controller straight away.
All changes in the parameter set are saved in non-volatile memory on clicking SAVE
PARAMETERS. They are still present after switching the controller off and on again.
The following sub-menus are available:
Operation mode: Switch between speed control and torque control, select your source of set values.
Fieldbus: Selects the fieldbus-operation of the drive. Adjustment for fieldbus- addresses and baudrate.
Current controller: Adjustment of rated and maximum current, as well as parameters of the current controller.
Speed controller: Adjustment of set value scaling, set value ramp and parameters of the speed controller.
Positioning: Adjustment of positioning and referencing parameters.
Digital outputs: Select functionality of digital outputs.
Limit switches: Configuration of the limit switches.
Analogue monitor: Select functionality and scaling of analogue outputs.
Fieldbus: Selects the fieldbus functionality.
Temperature probe motor: Switch between linear temperature probe KTY 83 and PTC resistor to protect the motor. If a
linear temperature probe is chosen, the temperature threshold must be adjusted (max. 130°C).
The actual motor temperature can be selected as monitoring function.
Save parameters: Saves parameters and settings in the DSV’s non-volatile memory.
