Attaching the EAP900H to a ceiling using the
provided T-Rail connectors:
1. Attach the T-Rail connectors to the bottom cover of the
EAP900H using the provided short screws.
Note: Two sizes of T-Rail connectors are included in the
mounting hardware kit: 15/16in (2.38cm) and 9/16in
(1.43cm). If extra space is required to accommodate drop
ceilingtiles,usetheprovidedspacersandlongscrews.
2. Line up the connected T-Rail connectors with an
appropriately sized rail and press the unit onto the rail
until it snaps into place.
Note: To protectyourEAP900H, usetheKensington
Security Slot to attach a cable lock (cable lock is not
included).
P2.6*10 Screw
Clip
T-Rail
Clip
Clips
Spacer
P2.6*25 Screw
