Physical Interface
Dimensions and Weights
Diameter:6.36”
Height:2.17”
1 Reset Button: Press and hold for over 10 seconds to reset to
factory default settings.
2 LED Indicators: LED lights for WPS, WLAN 5G, WLAN 2.4G,
Ethernetport,andPower
3 LAN Port (802.3at PoE): Ethernet port for RJ-45 cable.
4 Power Connector: 12V DC IN for Power.
5 Ceiling (Wall) Mount Hole: Using the provided hardware, the
EAP900H can be attached to a ceiling or wall.
6 Kensington Security Slot: ToprotectyourEAP900H,usethe
Kensington Security Slot to attach a cable lock.
3 4
1
2
5
6
