WSG-1068 ENGINE
Crankshaft Rear Oil Seal - Installation
1. CAUTION: Mating parts must make contact
to each other within 4 minutes and connecting
bolts must be torqued within 15 minutes after
applying sealant. Failure to follow this procedure
can cause future oil leakage.
Use silicone gasket and sealant F6AZ-19562-AA
or equivalent meeting Ford specification WSEM4G323-
A6.
NOTE: Sealant must be removed and area cleaned with
solvent if above instructions are not followed.
Use metal surface cleaner F4AZ-19A536-RA or
equivalent meeting Ford specification WSEM5B292-
A.
2. Using the Rear Crankshaft Seal Replacer and the
Rear Crankshaft Seal Adapter, install the crankshaft
rear oil seal.
3. With the Rear Crankshaft Seal Adapter still installed,
use the Rear Crankshaft Slinger Replacer and the
Rear Crankshaft Seal Replacer to install the rear main
seal slinger.
4. Install the flywheel; refer to Flywheel in this section.
5. Connect the battery ground cable.
