143

WSG-1068 ENGINE
44. As a post-check, verify timing mark alignment.
45. Position the LH and RH timing chain tensioner arm
(6L253) on the dowel pins. Position the timing chain
tensioners (6L266), and install the bolts.
46. Remove both the RH and LH retaining pins from the
timing chain tensioner assembly.
