WSG-1068 IGNITION SYSTEM
Fuel Select Operation
Fuel Select is Used to select ignition table for fuel type. The user has several options for this which is all
dependent on whether pin 7 of the 42 pin connector is Open, grounded or has 12 volts. The configurations are
listed below.
Fuel Select Configuration
1 GND = LP, Open = Gsln , +V = NG
2 Gnd = NG, Open = Gsln, +V = LP
3 Gnd/Open = Gsln, +V = LP
4 Gnd/Open = Gsln, +V = NG
5 Gasoline Only
6 LP Only
7 NG Only
8 Gnd/Open = LP, +V = NG
9 Gnd/Open = NG, +V = LP
10 Gnd = LP, Open = NG, +V = Gsln
