WSG-1068 IGNITION SYSTEM
42 Pin Engine Harness Connectors
F8JL-14324-AC & F8JL-14324-BA SH 4/5/06
42 pin engine to frame harness (6.8L)
GCP En
ine to Frame Harness Pinout
Harness Part # F8JL-14324-AC or BA
Pin # Wire Color Description
1 Red/Light Green +12 V switched
2 Tan/Yellow Tachometer output
3 Pink / Light Blue RS232 Rx / Self Test Input
4 Not populated Brake input
5 Pink/Black To fuel pump positive
6 Pink/Light Green To MIL
7 Y / Bk or BR / W Fuel select
8 Yellow Not used
9 Yellow Not used
10 Not populated Aux. Analog PUD1
11 Tan / Orange RS232 Tx
12 Not populated FPP2
13 Red/Light Blue Not used
14 Light Blue/Black FPP1
15 Dark Blue To start switch "S" terminal
16 Red/White Aux. PWM 4
17 Not populated Not used
18 White / Purple To fuel pump negative
19 Not populated Autocrank start
20 Not populated Not used
21 Not populated Aux. PWM 5
22 Purple Not used
23 Not populated GVS 2
24 Tan/Light Blue GVS 1
25 Black/Yellow IVS
26 Dark Green/White Oil pressure
27 Not populated Aux. Out 2
28 Not populated CAN +
29 Not populated CAN -
30 Not populated Not used
31 Brown/White +5v ref
32 Not populated Aux. Analog PD1
33 Gray/Red Analog return
34 Black/White Not used
35 Not populated Roadspeed +
36 Not populated Roadspeed -
37 Dark Green / Orange Analog aux. PUD2
