60
WSG-1068 ENGINE
2. Tighten the fasteners in two stages following the
sequence shown.
Stage 1: Tighten fasteners 1 through 5 to 20-30
Nm (15-22 lb/ft).
Stage 2: Tighten fasteners 6 through 15 to 40-55
Nm (30-41 lb/ft).
3. NOTE: Be sure to tighten the bolts through the front
of the oil pan
in two stages.
Stage 1: Tighten to 20 Nm (15 lb/ft).
Stage 2: Tighten an additional 60 degrees.
