38
1600751-4D
CAUTION:
The ultrasound treatment head is a precision instrument. Great care has been taken
during the development and in production to obtain the best possible beam
characteristics. Rough treatment (jarring or dropping) can adversely affect these
characteristics, and must therefore be avoided.
10.2.5 After treatment
Clean the skin of the patient and the ultrasound treatment head with a towel or tissue. Clean
the treatment head with a 70% alcohol solution.
Check for the effects that can be expected (for example pain, circulation and mobility).
Ask the patient to inform the therapist of any reactions.
10.3 StatUS
10.3.1 Connecting the StatUS- StatUS
applicator / ultrasound treatment head
Make sure that the logo of the ATUS-controller is
pointing upward.
Plug in the left plug of the ATUS-controller in
connection B of the UG-module [1].
Connect the right plug to the StatUS-module [2].
A special gel cushion (gel pad) is placed on the head for a proper transfer of the ultra-sound
energy. Do not use regular (fluid) Sonogel, as it is sucked into the vacuum pump.
The gel pad is held in position using a fixation. The vacuum pressure ensures that the head can
be placed on the body quickly and easily and that the head remains in contact with the body
surface.
