11.2.2 Navigation and display organization
The display is organized as a spreadsheet of four sheets, one for each channel. The channels
refer to the application modules accessible at the front of the unit. A sheet can be selected with
the channel selection button [1, 2, 3, 4] and shows the parameters belonging to that channel.
Each sheet has a tab, in which the output amplitude of that channel is displayed, as well as
other important information, such as the remaining treatment time. The tab information is
continuously visible.
Each sheet contains a list of therapy parameters. A parameter can be selected with the central
controller [5] and opened by pressing the confirmation button [6]. When opened, a pop-up
window appears, in which the parameter can be changed, using the central controller [5].
Pressing the confirmation button [6] again takes you back to the parameter list. To adjust the
output amplitude, first press the channel selection button [1, 2, 3, 4] and then adjust the
amplitude with central controller [5]. Pressing the confirmation button [6] takes you back to the
parameter list.
For some applications, such as interferential therapy and combination therapy, two adjacent
channels can be linked. Linked channels are indicated by a combined tab. The tab halves show
the output amplitude of each channel, while the parameters on the remainder of the sheet apply
to both channels.
When you turn on the unit, you will first enter the Home menu. In the Home menu none of the
channels are selected. The Home menu provides a structured access to all therapies available
within the unit, with appropriate parameter defaults. Just select a menu item using the central
controller [5] and press the confirmation button to navigate to the next screen. You can navigate
back to the previous screen by directing the cursor to the back arrow at the top of the screen
and pressing the confirmation button [6]. Anywhere in the navigation, you can jump back to the
Home menu, by pressing the Assist button [7] and selecting the Home entry in the pop-up list
that appears.
11.2.3 Home menu
The Home menu gives
access to all functions of
the unit. Select the desired
function or therapy with the
central controller [5] and
enter the next menu by
pushing the confirmation
button [6].
