1600751-4D
14.3 Vacuum unit (Vacotron)
Vacuum pressure : 10- 90 (0 – 600 mbar), continuously adjustable
Pulsed vacuum via vacuum range: adjustable from 10 – 80%
Hold time : 0 – 2,5 seconds in steps of 0,5 second
14.4 EMG
E.M.G. Channels : 2
Sensitivity : 0,5 µV – 10.000 µV
Raw EMG signal : 1.500 Hz
Sample frequency : 160 Hz
Bandwidth : 5 – 1.500 Hz
Filtering : digital
Pressure : 1 channel via internal sensor
Range : 0 – 360 hPa
14.5 Safety and Performance standards
IEC 60601-1 : General requirements for the safety of electrical medical
systems
Safety class according to IEC 60601-1: class I type BF
IEC 60601-2-5 : Particular requirements for the safety of ultrasonic
therapy equipment.
IEC 60601-2-10 : Particular requirements for the safety of nerve and
muscle stimulators.
IEC 60601-2-40 : Particular requirements for the safety of
electromyographs and evoked response equipment.
