1600751-4D
• Treatment and
registration runs
Note!
Following parameters are
adjustable during the
treatment:
• Sensitivity P
• Shift P
• Threshold P
11.2.10.m EMG feedback with 2 channels
The adjustment for two channels is the same as the adjustment for one channel. The feedback
is always for both channels as bar, curve ore combined curve visual in the display.
The real-time value will be showing in de display (in the right tab) as follow:
• E1 is for channel 1
• E2 is for channel 2
To change the read-out value in the display between EMG channel 1 and 2:
• Push the button [4] and change the read-out with the central controller [5] between E1
and E2.
•
11.2.10.n Analyze
At the end of the treatment
go to Analyze with the
central controller [5] and
push the confirmation
button [6]
