1600751-4D
11 Operating Instructions
11.1 Operator Controls
(See jacket flap)
[1] Standby button
With this push button the 6-series is switched between On and Standby.
Pushing this button for more than two seconds will reset the device.
[2] Connector for mains cable
To disconnect the device from the power line, unplug the power cord.
Type number/warning sticker
Provides information on the apparatus, such as type and serial number, as well as connection
data such as mains voltage and maximum current consumption.
[1] Selection button for:
Electrotherapy channel 1
Push the button to view or adjust all parameters of electrotherapy channel 1.
[2] Selection button for:
Electrotherapy channel 2.
Push the button to view or adjust all parameters of electrotherapy channel 2.
[3] Selection button for:
Ultrasound channel
Push the button to view or adjust all parameters of the ultrasound channel.
[4] Selection button for:
Optional module.
[5] Central controller
Use this controller to select menu items and to adjust all parameters including current amplitude
and ultrasound intensity.
[6] Confirmation button for:
Confirmation of all settings and selections.
[7] Assist button for:
Secondary functions, such as Stop, Home, Pause, Continue and Protocol Information. The
Assist button also provides access to the Vacotron module, when one is installed.
[8] Connection for Remote Control of Electrotherapy channels
[9] Connection Electrode Cable Electrotherapy channel 1
[10] Connection for additional accessories
[11] Connection Electrode Cable Electrotherapy channel 2
[12] Connection Ultrasound treatment head A
[13] Connection Ultrasound treatment head B
