1600751-4D
• Select a current wave
form with the central
controller [5] and enter
with the confirmation
button [6]
• Using the central
controller [5], to select
a parameter and push
the confirmation button
[6].
Adjust:
• Rest Time in sec
• Exercise Time
• Stimulation Time
• Cycles (amount of
repetitions)
• Sensitivity
• All stimulation
parameters.
Note!
Previous to the start via record we advise to adjust the stimulation level first.
Push the button [1] to activate the stimulation setting for channel 1 and adjust with the central
controller [5].
The current indications for the EMG channels will be displayed as usual in current channel 1
and 2. The electrode indication will change to E1 for channel 1 end E2 for channel 2
Go to record to start the treatment.
