EOS Compact DC/HC -
Installation
and Operating Instruc
tions
EN-21
Installa
tion
NO
TICE
Damage due to weather conditions
Precipitation, humidity, extrem
ely high/low outdoor tempera-
tures and direct sunlig
ht can damage the unit
, since it was not de-
signed for outdoor use.
Mount the control unit
inside the buil
ding.
W
e recommend mounting the control unit on the cabin’s ex
terior wall.
Mounting on the cabin’s exterior wall
A
Eye level
ca. 350 mm
A
20
22
