EOS Compact DC/HC - Installation and Operating Instructions EN-37
Installation
Material damage
Lighting and the control panel could become damaged if non-
dimmable light sources are installed. In this case, the warranty be-
comes void.
Do not install the lighting in areas with rising hot air.
The lighting must conform to protection class IPX4 (splash-
proof) and be resistant to ambient temperatures.
Connect only dimmable light sources.
3.8 Mounting the fan
An exhaust fan can be mounted in the cabin and set via the control unit.
The fan can be installed anywhere, however never near hot air that rises
from the heater.
The fan is not included in the scope of delivery. Observe the separate
installation instructions for the fan.
Fan requirements
Minimal output 5 W
Maximum output 100 W
Voltage 230 V 1N AC
Suitable for use in sauna cabins
