Section 9: Standard & Optional Machine
Features
138
so that the top surface is horizontal (see the flashlight on following pages). Insure
your cylinder is positioned so that the left end is close to, but not touching, the black
bumper. Using the clamp to hold the glass in place is optional. Some odd shaped
glasses rotate better if they are clamped to the drive wheels, but most glasses and
other cylindrical objects do not require clamping.
The glass in the photo does not require the use of the clamp. In fact, most standard
cylindrical shapes do not need the clamp. The clamp is used mostly for hard to rotate
cylinders or very light weight objects that need more than just gravity to hold in
place.
The clamp is holding a
glass against the drive
wheels.
