Section 9: Standard & Optional Machine
Features
143
In this example, the bottom of the logo
will engrave 4” (100 mm) up from the
bottom of the bottle.
Visualizing the orientation of the piece
you are engraving as it rests on the
rotary attachment will help in orienting
your artwork.
Imaginary glass.
Imaginary bottle.
The left edge of your page corresponds
to the edge of the black bumper on
your rotary attachment. Use the
distance from the left edge of the page
to determine how far down from the
top of the glass your artwork will
engrave. In this example you can see
that the top of the image will engrave
1” (25.4 mm) down from the top of the
glass.
