Interface Specifications
Your Stylus Scan is equipped with an 8-bit parallel interface and
a USB interface.
Parallel interface
The built-in parallel interface has the following characteristics.
Forward channel
U.S. model FCC part 15 subpart B class B
European model EN 55022 (CISPR Pub. 22) class B
EN 50082-1
IEC 801-2
IEC 801-3
IEC 801-4
EN 61000-3-2
EN 61000-3-3
Australian model AS/NZS 3548 class B
Data format 8-bit parallel, IEEE-1284 compatibility mode,
IEEE-1284 ECP mode
Synchronization See the IEEE-1284 specification
Handshake timing See the IEEE-1284 specification
Signal level IEEE-1284 Level 1 device
Connector 57-30360 Amphenol connector or equivalent
