Using the Optional Cut-Sheet Feeders
Two types of optional cut-sheet feeders are available for use with
your printer: the single-bin cut-sheet feeder (C80637
✽
) and the
high-capacity cut-sheet feeder (C80638
✽
). You can use either one
of these separately, or you can use both feeders together as a
double-bin cut-sheet feeder to automatically load two different
types of paper.
The single-bin cut-sheet feeder holds up to 50 single sheets. The
high-capacity cut-sheet feeder holds up to 150 single sheets or up
to 25 envelopes.
c
Caution:
Do not load multipart forms, carbon paper, or labels in the cut-
sheet feeder.
To install the single-bin, high-capacity, or double-bin cut-sheet
feeder, see the next section. However, before installing the
double-bin cut-sheet feeder, you must assemble it as described a
“Assembling the double-bin cut-sheet feeder” on page A-16. To
load paper in a bin, see “Loading paper in the single-bin cut-sheet
feeder” on page A-8, or “Loading paper in the high-capacity cut-
sheet feeder” on page A-12.
Note:
You cannot install and use the optional cut-sheet feeders when the tractor
unit is installed in the pull position. To remove the tractor from the pull
position, see “Removing the pull tractor” on page 2-24.
