EPSON FX-890/2190 Revision B
Appendix Parts List 128
543 "TRACTOR,RIGHT;EDGB"
544 "SHAFT,TR,DRIVE"
545 "SHAFT,TR,GUIDE"
546 "FRAME,TR,LEFT;EPAG"
547 "FRAME,TR,RIGHT;EPAG"
548 "LEVER,TR,LEFT;EDGB"
549 "LEVER,TR,RIGHT;EDGB"
550 PAPER SUPPORT
551 "SPUR GEAR,20"
552 RETAINING RING(B150300911)
556 "COVER,PAPER EJECT"
557 PAPER EJECT ASSY.
560 "LEAF SPRING,PAPER EJECT,DOUBLE"
561 "SPUR GEAR,15"
562 "SPUR GEAR,11.5"
563 "LEAF SPRING,PAPER EJECT,SINGLE"
564 "ROLLER,EJ,DRIVE"
565 "SLIDER,CR"
568 "CABLE,HEAD"
569 "ROLLER ASSY.,DRIVE"
570 PLATEN ASSY.
571 "FRAME,REAR"
572 "FRAME,BASE"
573 "COVER,PLATEN"
575 RIBBON MASK
Table 7-12. Parts List - FX-2190
Ref. No. Description
576 "PAPER GUIDE ASSY.,SUPPORT"
577 "GUIDE,PAPER LOAD"
578 "LEVER,RELEASE,TRANSMISSION;W"
579 "FRAME,FRONT"
580 "FRAME,SUB,RIGHT"
582 "SHAFT,CR,GUIDE"
583 "BUSHING,PARALLEL,ADJUST"
584 "LEVER,GAP,ADJUST"
585 "CAP,LEVER;EDGB"
586 "GROUNDING PLATE,MECHA"
587 "MOUNTING PLATE,MOTOR,CR"
588 "HOLDER,RIBBON MASK"
589 OIL PAD
590 "LEVER,RELEASE;EDGB"
591 "CAM,CLUTCH,TRACTOR"
592 "HOLDER,CABLE"
593 "COMBINATION GEAR,31,5,8"
594 "SPUR GEAR,27"
595 "SPUR GEAR,34.5"
596 "SPUR GEAR,34"
597 "SPUR GEAR,15"
598 INTERMITTENT GEAR
600 "EXTENSION SPRING,71"
601 "COMPRESSION SPRING,200"
603 C.B.S(P).(0) SCREW
Table 7-12. Parts List - FX-2190
Ref. No. Description
