EPSON FX-890/2190 Revision B
Appendix Parts List 122
7.4 Parts List
FX-890
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
NON FIG "SOFTWARE CD-ROM,EAI"
NON FIG USER'S GUIDE
100 "HOUSING ASSY.,LOWER"
101 FOOT
102 "HOUSING ASSY.,UPPER"
103 "COVER ASSY .,PRINTER,REAR"
104 "COVER ASSY .,PRINTER"
105 WING;EPAG
106 SHEET GUIDE ASSY
107 "COVER ASSY .,FRONT"
108 KNOB
109 "SHIELD,PLATE,UPPER"
110 SHIELD PLATE;B
111 SHIELD PLATE
112 GROUNDING PLATE
115 "COVER,CONNECTOR,UPPER;EPAG"
116 "MOUNTING,HOUSING"
117 "GUIDE,I/F BOARD"
120 "LOGO PLATE,12X48;C"
121 "SHEET,RELEASE,CAP"
122 "STOPPER,COVER,FRONT"
125 FAN ASSY.
127 C.B.S. SCREW(B300204311)
132 "GROUNDING PLATE,I/F"
133 "GROUNDING PLATE,I/F,UPPER"
137 "GROUNDING PLATE,BOTTOM"
138 "HOLDER,CABLE"
141 "SHEET,PANEL"
150 "DETECTOR ASSY.,CASE OPEN"
151 "HOLDER,DETECTOR"
180 "C.B.P-TITE SCREW,3X12,F/ZN"
181 C.B.S. SCREW(B300204211)
182 "C.B.P-TITE SCREW,3X8,F/ZN"
183 "C.B.S-TITE,3X20,F/ZN"
184 C.B.S. SCREW(B300204311)
185 C.P.SCREW(B010109511)
200 "BOARD ASSY., MAIN"
350 HARNESS AC INLET
372 HARNESS
CN1 CONNECTOR 57RE-40360-830B(D7B)
CN11 CONNECTOR
CN12 CONNECTOR
CN13 CONNECTOR
CN14 CONNECTOR
CN15 CONNECTOR
CN16 CONNECTOR
CN2 CONNECTOR
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
