EPSON FX-890/2190 Revision B
Adjustment Adjustment Overview 94
5.1 Adjustment Overview
5.1.1 Required Adjustment
This section describes the adjustments required after specified parts are removed or
replaced. Table 5-1 below shows the parts removed/replaced and corresponding
adjustments required.
NOTE 1:“O” :Adjustment required.
NOTE 2:“---” :Adjustment not required.
5.1.2 Adjustment Tools
Table 5-2 below shows the tools required for each adjustment.
Table 5-1. Required Adjustment
Removal or Replacement Requiring
Adjustment
Required Adjustment / Setting
Platen Gap
Bi-d
Adjustment
F/W Reload
Printhead Removal or Replacement O O ---
Printer Mechanism Replacement --- O ---
Printer Mechanism Removal O O ---
Main Boar Replacement --- O O
Timing Belt Replacement O O ---
Platen Replacement O --- ---
Carriage Assembly Replacement O O ---
CR Motor Replacement --- O ---
EEPROM Clear --- O ---
Table 5-2. Adjustment Tools
Adjustment Required Tool
Platen Gap Thickness gauge (0.37 mm, 0.40 mm)
Bi-d Adjustment
 Adjustment program (for FX-890/2190)
 Control panel operation (built-in function)

Epson 890N - FX B/W Dot-matrix Printer Specifications

General

Brand	Epson
Model	890N - FX B/W Dot-matrix Printer
Category	Printer
Language	English
