EPSON FX-890/2190 Revision B
Appendix Parts List 123
CN20 CONNECTOR
CN3 CONNECTOR
CN5 CONNECTOR
CN6 CONNECTOR
CN7 CONNECTOR(X600440310)
CN8 CONNECTOR(X600440120)
CN9 CONNECTOR(X600440120)
D1 DIODE
D4 DIODE(X320010829)
D7 DIODE(X320011839)
D8 DIODE(X320011839)
IC1 ASIC
IC11 EEPROM
IC13 RESET IC
IC15 HYBRID IC SLA7024M
IC4 FLASH ROM
IC9 IC
500 PRINTER MECHANISM(ASP)M-3Q10-100
501 "FRAME ASSY.,RIGHT"
502 "FRAME ASSY.,LEFT"
503 "MOTOR ASSY.,CR"
504 RD ASSY.
511 "MOTOR,PF"
522 "DETECTOR,HP"
523 "HARNESS,HP"
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
524 CONNECTOR SWITCH;B
525 "PAPER GUIDE ASSY.,REAR"
526 "SHAFT,RELEASE"
527 "HARNESS,PE,FRONT"
528 "HARNESS,PE,REAR"
529 "HARNESS,RE"
530 "DETECTOR,PE,FRONT,S"
531 "DETECTOR ASSY., REAR"
532 "ROLLER,PF,DRIVEN,LOWER"
533 "ROLLER ASSY.,PF"
534 "EXTENSION SPRING,70"
535 "COMPRESSION SPRING,1000"
536 CARRIAGE SUB ASSY.
537 "SLIDER,CR"
541 TRACTOR ASSY.
542 "TRACTOR,LEFT;EDGB"
543 "TRACTOR,RIGHT;EDGB"
544 "SHAFT,TR,DRIVE"
545 "SHAFT,TR,GUIDE"
546 "FRAME,TR,LEFT;EPAG"
547 "FRAME,TR,RIGHT;EPAG"
548 "LEVER,TR,LEFT;EDGB"
549 "LEVER,TR,RIGHT;EDGB"
550 PAPER SUPPORT
551 "SPUR GEAR,20"
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
