EPSON FX-890/2190 Revision B
Appendix Parts List 124
552 RETAINING RING(B150300911)
556 "COVER, PAPER EJECT"
557 "FRAME,PAPER EJECT;EPAG"
560 "LEAF SPRING,PAPER EJECT,DOUBLE"
561 "SPUR GEAR,15"
562 "SPUR GEAR,11.5"
563 "LEAF SPRING,PAPER EJECT,SINGLE"
564 "ROLLER,PAPER EJECT,DRIVE"
568 "HOLDER,CABLE,HEAD"
569 "ROLLER ASSY,DRIVE"
570 PLATEN ASSY.
572 "BUSHING,8,RIGHT"
573 "COVER,PLATEN"
574 "BUSHING,8,LEFT"
575 RIBBON MASK
576 "PAPER GUIDE ASSY.,SUPPORT"
577 "GUIDE,PAPER LOAD"
578 "FRAME,REAR"
579 "FRAME,FRONT"
580 "FRAME,SUB,RIGHT"
581 "GROUNDING PLATE,MECHA"
582 "FRAME,BASE"
583 "BUSHING,PARALLEL,ADJUST"
584 "LEVER,GAP,ADJUST"
585 "CAP,LEVER;EDGB"
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
587 "MOUNTING PLATE,MOTOR,CR"
588 "HOLDER,RIBBON MASK"
589 OIL PAD(F334005140)
590 "LEVER,RELEASE;EDGB"
591 "CAM,CLUTCH,TRACTOR"
592 "HOLDER,CABLE"
593 "COMBINATION GEAR,31,5,8"
594 "SPUR GEAR,27"
595 "SPUR GEAR,34.5"
596 "SPUR GEAR,34"
597 "SPUR GEAR,15"
598 INTERMITTENT GEAR
599 "LEVER,RELEASE,TRANSMISSION;W"
600 "EXTENSION SPRING,71"
601 "COMPRESSION SPRING,200"
602 "SPRING PIN,2X18,F/B"
603 C.B.S(P).(0) SCREW
607 PLAIN WASHER(B100166012)
608 C.B.SCREW(B010303411)
609 C.B.SCREW(B010303511)
610 C.B.S. SCREW(B300204311)
613 "SHAFT,MOUNT,CR"
614 TOOTHED LOCK WASHER A
615 HEXAGON NUT(B070200411)
617 LEAF SPRING(B101253990)
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
