Epson EB-770F User Manual

105
7. Press the arrow buttons to adjust the image shape as necessary. Press Enter to return to the
area selection screen.
Note: You can also use the numeric buttons on the remote control to adjust the image shape. If one
of the directional arrows on the screen turns gray, you cannot adjust the shape any further in that
direction.
8. When you are finished, press Esc.
The Geometry Correction setting is now set to Quick Corner in the projector's Installation menu. If you
press the keystone adjustment buttons on the control panel, the area selection screen appears.
Note: To save the current image shape, select Memory > Save Memory. You can save up to three
image shapes in the projector's memory.
Parent topic: Image Shape
Correcting Image Shape with Arc Correction
You can use the projector's Arc Correction setting to adjust the curve or arc of the sides of your image.
Note: If you change the Screen Type setting or adjust the image position, your image adjustments are
reset.

Epson EB-770F Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	57 - 150 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Focus	Manual
Throw ratio	0.25
Zoom capability	Yes
Fixed focal length	3.7 mm
Light source type	Laser
Service life of light source	- h
Product type	Ultra short throw projector
Product color	White
Market positioning	Education
Cable lock slot type	Kensington
Audio (L/R) in	-
Composite video in	0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
RMS rated power	16 W
Number of built-in speakers	1
Analog signal format system	Not supported
Power source	AC
Power consumption (standby)	2 W
Power consumption (typical)	263 W
Display diagonal	0.62 \
Noise level	37 dB
Noise level (economic mode)	27 dB

Weight and Dimensions

Depth	395 mm
Width	357 mm
Height	165 mm
Weight	5900 g
