108
8. When you are finished, press Esc.
Note: To save the current image shape, select Memory > Save Memory. You can save up to three
image shapes in the projector's memory.
Parent topic: Image Shape
Correcting Image Shape with Point Correction
You can use the projector's Point Correction feature to fine-tune the image shape using points on a grid.
This is useful for adjusting overlapping areas in multiple projected images that do not line up correctly.
1. Turn on the projector and display an image.
2. Press the Menu button.
3. Select Installation > Geometry Correction > Point Correction.
Note: If you see a confirmation message, select Yes and press Enter.
4. Select the Point Correction setting again and press Enter.
Note: For fine tuning, select Quick Corner from the Point Correction menu to roughly correct the
shape and size of an image and then select Point Correction to adjust them more precisely.
5. Select the number of grid lines to display and press Enter.
You see a grid on the projected image.
Note: If you need to change the color of the grid lines, press Esc and then select a different Pattern
Color setting in the Point Correction menu.
