Art-Net Channel Definitions
Art-Net is an Ethernet communication protocol based on the TCP/IP protocol. You can control the
projector by using a DMX controller or an application system.
The following table lists the channel definitions used to control the projector in Art-Net.
Channel/Function Operation Parameters Description
1 Adjusting light
(dimming)
0% to 100% 0 to 255 (default is 0) Adjusts the image
brightness
2 Shutter control Shutter open
Non-operational
Shutter closed
0 to 63 (default is 128)
64 to 191
192 to 255
Enables/disables A/V
Mute
3 Switch source Non-operational
HDMI
LAN
SD Player
Spotlight
Non-operational
0 to 7 (default is 0)
8 to 15
16 to 23
24 to 31
32 to 39
40 to 255
Switches to the
specified source
7 Zoom Electronic Tele/Wide 0 to 255 (default is 255) Zooms using the
specified amount of
movement

Epson EB-770F Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	57 - 150 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Focus	Manual
Throw ratio	0.25
Zoom capability	Yes
Fixed focal length	3.7 mm
Light source type	Laser
Service life of light source	- h
Product type	Ultra short throw projector
Product color	White
Market positioning	Education
Cable lock slot type	Kensington
Audio (L/R) in	-
Composite video in	0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
RMS rated power	16 W
Number of built-in speakers	1
Analog signal format system	Not supported
Power source	AC
Power consumption (standby)	2 W
Power consumption (typical)	263 W
Display diagonal	0.62 \
Noise level	37 dB
Noise level (economic mode)	27 dB

Weight and Dimensions

Depth	395 mm
Width	357 mm
Height	165 mm
Weight	5900 g
