Epson EB-770F User Manual

194
Warning: Do not place flammable objects in front of the lens. If you schedule a projector to turn on
automatically, flammable objects in front of the lens could catch on fire.
Note: Light Source Calibration events do not start if the projector is not used continuously for at least 20
minutes, or if the projector is regularly turned off by shutting off the power outlet. Set Light Source
Calibration events to occur only after 100 hours of usage (EB-770F/EB-775F).
Note: The Schedule setting in the Menu Protection menu must be turned off to schedule an event.
1. Set the date and time in the Management menu.
2. Press the Menu button.
3. Select the Management menu and press Enter.
4. Select the Schedule Settings setting and press Enter.
5. Select the Schedule menu and press Enter.
6. Select Add New and press Enter.
7. In the Event Settings section, select the events you want to have occur. (Select No Change for
events that you do not want to occur.)

Epson EB-770F Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	57 - 150 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Focus	Manual
Throw ratio	0.25
Zoom capability	Yes
Fixed focal length	3.7 mm
Light source type	Laser
Service life of light source	- h
Product type	Ultra short throw projector
Product color	White
Market positioning	Education
Cable lock slot type	Kensington
Audio (L/R) in	-
Composite video in	0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
RMS rated power	16 W
Number of built-in speakers	1
Analog signal format system	Not supported
Power source	AC
Power consumption (standby)	2 W
Power consumption (typical)	263 W
Display diagonal	0.62 \
Noise level	37 dB
Noise level (economic mode)	27 dB

Weight and Dimensions

Depth	395 mm
Width	357 mm
Height	165 mm
Weight	5900 g
