Epson EMP-X3 User Manual

58
Maintenance
Replacing Consumables
This section explains how to replace the remote control batteries, the lamp,
and the air filters.
If delays in the responsiveness of the remote control occur or if it does not
operate after it has been used for some time, it probably means that the
batteries are becoming flat. Replace the batteries. Have two spare AAA-
size alkali batteries ready to use when required.
PROCEDURE
A
Remove the battery cover.
While pushing the catch of the battery compartment cover, lift
the cover up.
B
Insert the batteries.
Check the positions of the (+) and (–) marks inside the battery
holder to ensure that the batteries are inserted the correct way.
C
Replace the battery cover.
Press the battery compartment cover until it clicks into place.
Replacing the batteries
Make sure you read the Safety Instructions/World-Wide
Warranty Terms before handling the batteries.
Catch

Epson EMP-X3 Specifications

General

Display resolution	1024 x 768 pixels
Number of colors	16.78 million colors
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 92 kHz
Contrast ratio (typical)	400:1
Projector native resolution	XGA (1024x768)
Video in	Mini D-sub 15pin x 1
I/O ports	USB B x1, RCA x 1, Mini DIN, Mini D-sub 15pin
Audio input	RCA x 2
Aspect ratio	4:3
Dimensions (WxDxH)	327 x 246 x 86 mm
Power requirements	100 - 240V ±10%, 50 / 60Hz AC
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Noise level	30 dB
Power consumption (typical)	240 W
Operating temperature (T-T)	5 - 35 °C
Market positioning	Home cinema

Weight and Dimensions

Weight	2600 g
