63
Maintenance
If the air filters are broken or if the warning message reappears after they
have been cleaned, they should be replaced.
The air filter can be replaced even if the projector is installed on a ceiling.
PROCEDURE
A
After you turn off the projectors power, and the
confirmation buzzer beeps twice, disconnect the
power cable.
B
Remove the air filter.
Put your finger into the recess of the air filter and slide it
forward to remove it.
C
Install the new air filter.
Slide the air filter covers in from the outside and push them in
until they click into place.
Replacing the Air Filter
Recess
Dispose of used air filters properly in accordance with
your local regulations.
Air filter frame: Polycarbonate, ABS plastic
Filter: Polyurethane foam

Table of Contents

Other manuals for Epson EMP-X3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EMP-X3 and is the answer not in the manual?

Epson EMP-X3 Specifications

General IconGeneral
Display resolution1024 x 768 pixels
Number of colors16.78 million colors
Vertical scan range50 - 85 Hz
Horizontal scan range15 - 92 kHz
Contrast ratio (typical)400:1
Projector native resolutionXGA (1024x768)
Video inMini D-sub 15pin x 1
I/O portsUSB B x1, RCA x 1, Mini DIN, Mini D-sub 15pin
Audio inputRCA x 2
Aspect ratio4:3
Dimensions (WxDxH)327 x 246 x 86 mm
Power requirements100 - 240V ±10%, 50 / 60Hz AC
Lamp typeUHE
Lamp power170 W
Light source typeLamp
Service life of light source2000 h
Noise level30 dB
Power consumption (typical)240 W
Operating temperature (T-T)5 - 35 °C
Market positioningHome cinema
Weight and Dimensions IconWeight and Dimensions
Weight2600 g
