Epson EMP-X3 User Manual

2
Contents
Projection Procedure
Setup ....................................................................................... i
Using the remote control.............................................................. i
Connecting to Visual Equipment ............................................ ii
Turning on and Projecting ..................................................... iii
No image is projected ................................................................ iii
Adjusting Position and Focus .................................................... iii
Turning the Projector off ........................................................... iii
Projector Features..................................................................4
Part Names and Functions.....................................................6
Front/Top .................................................................................... 6
Control Panel .............................................................................. 7
Rear (EMP-X3)........................................................................... 8
Rear (EMP-82/62)....................................................................... 9
Base........................................................................................... 10
Remote Control......................................................................... 11
Adjusting and changing the image
Adjusting the Image Quality .................................................13
Adjusting Computer Images and RGB Video Images .............. 13
Selecting the Projection Quality (Color Mode) ........................ 15
Adjusting the Volume ...........................................................17
Changing the Projected Image (Source Search)..................18
Automatically Detect Incoming Signals and Change
the Projected Image (Source Search)....................................... 18
Changing Directly from the Remote Control............................ 18
Useful Functions
Functions for Enhancing Projection ..................................... 20
Pausing the Image and Sound (A/V Mute) ............................... 20
Freezing the Image (Freeze)...................................................... 20
Changing the Aspect Ratio (Resizing) ...................................... 21
Displaying the Pointer (Pointer)................................................ 21
Enlarging Part of the Image (E-Zoom) ..................................... 22
Using the Remote Control to Operate the Mouse Pointer
(Wireless Mouse) ..................................................................... 23
Security functions................................................................. 26
Preventing theft (Password Protect).......................................... 26
Operation Button Lock Function............................................... 29
Configuration Menu
Using the Configuration Menu ............................................. 32
List of Functions................................................................... 33
"Image" Menu ........................................................................... 33
"Signal" Menu ........................................................................... 34
"Settings" Menu ........................................................................ 36
"Extended" Menu ...................................................................... 37
"Info" Menu............................................................................... 39
"Reset" Menu ............................................................................ 40
Troubleshooting
Using the Help ..................................................................... 42
Problems Solving ................................................................. 44
Reading the Indicators............................................................... 44
When the Indicators Provide No Help ...................................... 47

Epson EMP-X3 Specifications

General

Display resolution	1024 x 768 pixels
Number of colors	16.78 million colors
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 92 kHz
Contrast ratio (typical)	400:1
Projector native resolution	XGA (1024x768)
Video in	Mini D-sub 15pin x 1
I/O ports	USB B x1, RCA x 1, Mini DIN, Mini D-sub 15pin
Audio input	RCA x 2
Aspect ratio	4:3
Dimensions (WxDxH)	327 x 246 x 86 mm
Power requirements	100 - 240V ±10%, 50 / 60Hz AC
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Noise level	30 dB
Power consumption (typical)	240 W
Operating temperature (T-T)	5 - 35 °C
Market positioning	Home cinema

Weight and Dimensions

Weight	2600 g
